The KX TreeShears is from the forested region of Finland. It is a user-friendly, efficient, and lightweight tree shear that can be used for a variety of applications. Thanks to its modular structure and easily removable blade, tree felling, clearing, and installation tasks can be carried out effortlessly. The optional collector allows for multiple consecutive cuts, making the timber harvesting process more efficient.
The KX is a new type of energy timber grab. The result of extensive experience and continuous development work, it is a user-friendly, efficient, and lightweight energy grab that can be used for a wide variety of applications. Thanks to its modular structure and easily detachable blade, logging, clearing, and installation tasks are effortless. The optional collector makes multiple consecutive saw cuts possible, increasing efficiency during the timber harvest.
The KX Tree Shear is a powerful and versatile grab for efficiently pruning and felling trees and bushes. This machine is equipped with a high-quality hydraulic blade, allowing both precise and heavy-duty tasks to be performed.
The KXZ Tree Shear is an advanced version of the KX series, with additional features for precision and durability. The key difference is the rotatable head (infinitely rotatable), which provides more flexibility when positioning and working in tight spaces.
| Model | KX210 | KX280 | KX350 | KXZ210+E210 | KXZ280+E280 | KXZ350+E350 |
|---|---|---|---|---|---|---|
| Weight: | 150 | 300 | 670 | 150 | 250 | 780 |
| Suitable for excavators: | 1,5 – 5 ton | 5 – 15 ton | 13 – 25 ton | 1,5 – 5 ton | 2,5 – 6 ton | 15 – 25 ton |
| Gripper opening: | 670 mm | 890 mm | 1145 mm | 670 mm | 890 mm | 1145 mm |
| Max. cutting diameter: | 210 mm | 280mm | 350 mm | 210 mm | 280 mm | 1145 mm |
| Max. allowable pressure: | 300 bar | 300 bar | 300 bar | 300 bar | 300 bar | 300 bar |
The collector speeds up the energy wood harvesting process. It holds the felled wood in the grab and enables up to 20 consecutive saw cuts.
Technical information
Suitable for excavators: 2.5 – 5 tons
Weight: 78 kg
Warranty: 12 months
Compatible with KX210/280/350
The removable extension increases the reach of the grab.
Technical information
Suitable for excavators: 1.5 – 5 tons
Weight: 42 kg
Warranty: 12 months
Compatible with KX210/280/350
The removable stem support stabilizes the trees and improves efficiency during operation.
Compatible with KX210 / KX280 / KX350 and KXZ210+E210 / KXZ280+E280 / KXZ350+E350.
